Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
BBS-20
BBS-20 is a 20 Amp, 48 Volt fast-acting midget fuse from Eaton's Bussmann BBS series designed for supplemental circuit protection.This fuse features a ferrule end x ferrule end design with nickel-plated brass endcaps and a fiber tube body. It is rated for 48 VAC operation with a 10kA interrupting rating at 48 volts. The compact size is approximately 13/32 inch diameter by 1-3/8 inch length. It is UL listed and CSA certified for safety and reliability.
- Key Specifications
- Amperage: 20 A
- Voltage Rating: 48 VAC
- Fuse Type: Fast Acting
- Interrupt Rating: 10 kA at 48 V
- Body Style: Midget Cartridge
- End Caps: Nickel-plated brass
- Dimensions: 13/32" diameter x 1-3/8" length
- Mounting Type: Ferrule end x ferrule end
- Series: Bussmann BBS
- Certifications: UL Listed, CSA Certified
- Part Number: BBS-20
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : BBS Series
- Type : BBS
- Voltage : 48
- Amperage : 20
- AIC rating : 10kA@48V
- Barrels : 1
- UPC : 051712707541
- GTIN : 00051712707541
- Country of Origin : Mexico
- Dimensions : 0.41 in x 1.38 in x 0.41 in (Length/Depth x Height x Width)
- Weight : 0.12
- Certification : CE, CSA, UL Listed
