Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
BAB3035HV
BAB3035HV is a Cutler Hammer thermal magnetic circuit breaker designed for industrial applications with bolt-on mounting.BAB3035HV features a 35 ampere rating, 240 volt AC operation, and three poles for three-phase power protection. It has a fixed thermal and magnetic trip unit calibrated for 50¡C and a 10 kA interrupt rating. This breaker is non-interchangeable and part of the Quicklag series, suitable for panel mounting with flexible power feed connections. It is UL and CSA approved for safety and reliability.
- Key Specifications
- Amperage: 35 Amps
- Voltage: 240 VAC
- Poles: 3 (Three-Pole)
- Mounting Type: Bolt-On
- Interrupt Rating: 10 kA
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Series/Frame: Quicklag (BAB)
- Calibration Temperature: 50¡C
- Approvals: UL, CSA
- Wire Size: 14 to 4 AWG Aluminum/Copper
- Non-Interchangeable Design
Specifications
- Part Number: BAB3035HV
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Quicklag
- Type : BAB
- Voltage : 240
- Amperage : 35
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-On
Product Data
- UPC : 786679842362
- GTIN : 786679842362
- Dimensions : 3.8 in x 4.7 in x 3.2 in (Length/Depth x Height x Width)
- Weight : 0.95
- Standards : HACR rated
- Certification : UL Listed,CSA Certified
