B70 - Square D Thermal Unit Overload Relay 32.2-45A Class 20 NEMA Size 2 Motor Control

SKU: B70-New
Condition: New
Price:
$20.47
Stock:
Low inventory, please call for stock check
Factory Lead Time: 3 business days. Ships based on manufacturer availability when out of stock. All factory-ordered products are non-cancelable and non-returnable.

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

B70 Square D B Series Heater Element 48 Full load amps - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
B70 Square D B Series Heater Element 48 Full load amps - Essential Electric Supply

Description

B70


B70 is a Square D thermal unit overload relay designed for motor control applications with a full load amperage range of 32.2 to 45 amps and Class 20 trip. This thermal unit is compatible with a variety of overload relays and is suitable for switching electric motors in industrial and commercial environments. The B70 thermal unit features a plug-on mounting design and utilizes a melting alloy sensing method for reliable overload protection. It is rated for up to 600V and is available in NEMA Size 2, making it a versatile solution for motor control circuits. The unit is constructed for durability and ease of installation, ensuring consistent performance in demanding applications.
  • Full Load Amperage: 32.2 to 45A
  • Maximum Voltage: 600V
  • Mounting Type: Plug-On
  • Motor Tripping Class: 20
  • NEMA Size: 2
  • Sensing Method: Melting Alloy
  • Suitable for Motor Control Applications
  • Compatible with Various Overload Relays
  • Series: B
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: B70
  • Manufacturer : Square D
  • Brand : Square D
  • Category : Motor Control
  • Item Subcategory : Heater Element
  • Family : B Series
  • Type : B
  • Full Load Amp Minimum : 41.5
  • Full Load Amp Maximum : 48

Product Data

  • UPC : 785901587651
  • GTIN : 00785901587651
  • Weight : 5
