B380H00S01 - Siemens 80A 240V 3 Pole Molded Case Circuit Breaker BLH Series Bolt-On Mounting

B380H00S01

B380H00S01 is a Siemens 3 pole molded case circuit breaker rated for 80 amps and 240 volts AC, designed for reliable circuit protection in commercial and industrial applications.This Siemens BLH series breaker features bolt-on mounting and a 22kA interrupt rating at 240V, ensuring high fault current interruption capability. It includes a shunt trip for remote tripping functionality and is suitable for 3-phase systems. The breaker meets industry certifications for safety and performance.

• Amperage: 80 Amps
• Voltage: 240 VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 22kA @ 240V
• Series/Frame: BLH Series
• Trip Unit: Shunt Trip
• Phase: 3
• Type: Molded Case Circuit Breaker
• Certifications: Industry Standard Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: B380H00S01
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : BLH
• Voltage : 240
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 125A/BLH
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 8 AWG Max. Wire Size 2 AWG (Al), 4 AWG (Cu)
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 783643269019
• GTIN : 00783643269019
• Country of Origin : Mexico
• Dimensions : 5.906 x 3.937 x 3.937 inch
• Weight : 1.609
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
