Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
B380
B380 is a Siemens 80 Amp 3 Pole 240 Volt Bolt-On Circuit Breaker from the BL Series designed for reliable circuit protection.This molded case circuit breaker features a thermal magnetic trip unit, a 10,000 Amp interrupt rating at 240 VAC, and is UL Listed, CSA Certified, HACR Rated, and NOM Certified. It is a panelboard mounting breaker with a bolt-on connection type, suitable for three-phase applications.
- Manufacturer: Siemens
- Series: BL
- Amperage: 80 Amp
- Voltage: 240 Volt AC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 10,000 Amps
- Trip Unit: Thermal Magnetic
- Approvals: UL Listed, CSA Certified, HACR Rated, NOM Certified
- Phase: 3
- Dimensions: Approx. 3" W x 3" D x 3-3/4" H
Specifications
- Part Number: B380
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BL Series
- Type : BL
- Voltage : 240
- Amperage : 80
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-on
- Functions : Long Time and Instantaneous Trip
- Terminal Connection : Lug
- Frame Size : 125A/BL
- MCM Size : Min. Wire Size 2 AWG (Al), 4 AWG (Cu) Max. Wire Size 1/0 AWG
- Breaker Type : Standard
- Protection : Thermal Magnetic
Product Data
- UPC : 783643263789
- GTIN : 00783643263789
- Country of Origin : Mexico
- Dimensions : 2.756 x 2.756 x 2.756 inch
- Weight : 1.058 lb
- Panel Type : Siemens P1 Panelboards
- Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
- Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
