B350H - Siemens 50 Amp 3 Pole 240VAC Bolt-On Molded Case Circuit Breaker 22kA Interrupting Rating

B350H

B350H - Siemens 3-pole, 50-amp thermal magnetic molded case circuit breaker with bolt-on mounting for P1 panelboards.The Siemens B350H features a BL series frame with 240VAC rating, 22kAIC interrupting capacity at 240VAC, and long time plus instantaneous trip functions. It includes load side lugs and measures 4in L x 3in W x 3in H for reliable panelboard protection.

• Amperage: 50A
• Voltage: 240VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 22kAIC @ 240VAC
• Series/Frame: BL / B
• Trip Unit: Thermal Magnetic
• Functions: Long Time, Instantaneous
• Terminal: Load Side Lug
• Approvals: UL, CSA
• For Use With: P1 Panelboards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: B350H
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : BLH
• Voltage : 240
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 22kA@240V
• Connection : Bolt-on
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/BLH
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 8 AWG Max. Wire Size 2 AWG (Al), 4 AWG (Cu)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643264021
• GTIN : 00783643264021
• Country of Origin : Mexico
• Dimensions : 3.937 x 2.756 x 2.756 inch
• Weight : 1.036
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
