Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
B215HID
B215HID is a Siemens 15 amp, 240 volt, 2 pole molded case circuit breaker from the B Series with bolt-on mounting.This circuit breaker features a thermal/magnetic trip unit and a 10 kA interrupting rating at 240 VAC. It is designed for single-phase applications and provides reliable overcurrent protection. The breaker is UL listed and suitable for use in a variety of electrical distribution systems.
- Amperage: 15 A
- Voltage: 240 VAC
- Number of Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 10,000 AIC (10 kA) at 240 VAC
- Series/Frame: B Series
- Trip Unit: Thermal/Magnetic
- Phase: Single Phase
- Certifications: UL Listed
- Frame Type: B
Specifications
- Part Number: B215HID
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BL Series
- Type : BL
- Voltage : 240
- Amperage : 15
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous Trip
- Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643274730
- GTIN : 00783643274730
- Country of Origin : Mexico
- Dimensions : 3.937 x 1.969 x 2.756 inch
- Weight : 0.661
- Panel Type : Siemens P1 Panelboards
- Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
- Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
