Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
B215GF
Siemens B215GF is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial power distribution systems. This 600V AC device features a 15A current rating and is engineered with a compact, durable housing constructed from high-strength thermoset materials. The breaker complies with UL 489 standards for circuit breaker enclosures and is certified for use in commercial and industrial applications. Typical installations include panelboards, switchboards, and motor control centers where robust circuit protection is required. Key Features & Specifications
- Type: Molded Case Circuit Breaker
- Voltage: 600V AC
- Current: 15A
- Interrupting Capacity: 18kA at 240V AC
- Poles: 2
- Mounting: Fixed
- Termination: Screw Type
- Standards: UL 489
Specifications
- Part Number: B215GF
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : BL Series
- Type : B
- Voltage : 120/240VAC
- Amperage : 15
- Phase : 1
- Poles : 2
- AIC rating : 10kAIC at 240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
- Compatible Frames : B
Product Data
- UPC : 195125299580
- Country of Origin : Philippines
- Dimensions : 5.00 x 2.00 x 3.00 inch
- Weight : 0.8
- Panel Type : Siemens P1 Panelboards
- Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
- Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
