B150HH - Siemens 50 Amp 120 Volt 1 Pole Molded Case Circuit Breaker 65kA Interrupt Rating

B150HH

B150HH is a Siemens 50 Amp, 120 Volt, 1 Pole molded case circuit breaker designed for reliable circuit protection.This breaker features a thermal magnetic trip unit, a 65kA interrupt rating at 240VAC, and a bolt-on mounting type. It belongs to the Siemens Type HBL series and is suitable for panel mounting applications. The breaker is UL listed and compliant with industry safety standards.

• Amperage: 50 Amps
• Voltage: 120 Volts AC
• Poles: 1
• Interrupt Rating: 65kA @ 240VAC
• Mounting Type: Bolt-on
• Series/Frame: Type HBL
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed
• Panel Mounted Molded Case Circuit Breaker
• Compact Dimensions for Easy Installation

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: B150HH
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BL Series
• Type : HBL
• Voltage : 120
• Amperage : 50
• Phase : 1
• Poles : 1
• AIC rating : 65kA@240V
• Connection : Bolt-on
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/BL
• Temp Rating : -13‰ÛÒ158 å¡F (-25‰ÛÒ70 å¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 783643264120
• GTIN : 00783643264120
• Country of Origin : Mexico
• Dimensions : 2.563 x 1.00 x 3.122 inch
• Weight : 0.309
• Panel Type : Siemens P1 Panelboards
• Standards : CSA Certified, HACR Rated, NOM Certified, UL Listed
• Certification : CSA Certified, HACR Rated, NOM Certified, UL Listed
