Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
ATQ3-1/2
ATQ3-1/2 is a time-delay midget fuse from Mersen Ferraz Shawmut, designed for reliable circuit protection in demanding electrical applications.
This fuse features a 3.5A current rating, 500VAC voltage rating, and a 10kA interrupting capacity. It is part of the ATQ series, offers clip mounting, and is UL listed and CSA certified for safety and compliance. The time-delay characteristic makes it suitable for circuits with high inrush currents, providing enhanced protection for sensitive equipment.
-
Key Specifications
- Part Number: ATQ3-1/2
- Manufacturer: Mersen Ferraz Shawmut
- Amperage: 3.5A
- Voltage: 500VAC
- Poles: 1
- Mounting Type: Clip
- Interrupt Rating: 10,000A (10kA)
- Series/Frame: ATQ
- Trip Unit: Time Delay (12 seconds at 200% rating)
- Certifications: UL 248-14, CSA C22.2
- Body Material: GMG
- Length: 1.5" (38.1 mm)
- Diameter: 0.41"
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: ATQ3-1/2
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : ATQ
- Voltage : 500
- Amperage : 3
- AIC rating : 10kA@500V
- Diameter : 0.41
- Class Rating : midget
- Barrels : 1
Product Data
- UPC : 782001906085
- GTIN : 00782001906085
- Country of Origin : Mexico
- Dimensions : x 1-1/2 in x
- Weight : 5
- Certification : CSA, UL
