Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
ATQ1
ATQ1 is a Mersen midget time-delay fuse rated at 1.8 amperes and 500 volts AC, designed for reliable circuit protection.ATQ1 fuses feature Amp-Trap technology, providing time-delay characteristics suitable for supplemental circuit protection with a high interrupting rating. This fuse is compact with a ferrule mounting style and complies with UL 248-14 and CSA C22.2 certifications.
- Amperage: 1.8A
- Voltage Rating: 500VAC
- Fuse Type: Midget Time-Delay
- Series: Amp-Trap ATQ
- Mounting Type: Ferrule
- Interrupting Rating: 10,000 Amps
- Length: Approximately 1.5 inches
- Diameter: Approximately 0.41 inches
- Certifications: UL 248-14, CSA C22.2
- Application: Supplemental circuit protection
Specifications
- Part Number: ATQ1
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : ATQ
- Voltage : 500
- Amperage : 1
- AIC rating : 10kA@500V
- Diameter : 0.41
- Class Rating : midget
- Barrels : 1
Product Data
- UPC : 782001903480
- GTIN : 00782001903480
- Country of Origin : Mexico
- Dimensions : x 1-1/2 in x
- Weight : 5
- Certification : CSA, UL
