ATDR1/4 - Mersen Ferraz Shawmut 1/4 Amp 600V Class CC Time Delay Fuse

ATDR1/4

ATDR1/4 is a Mersen Ferraz Shawmut Class CC time delay fuse designed for overcurrent protection in low voltage applications.ATDR1/4 features a 1/4 ampere rating and 600 volts AC voltage rating, suitable for motor protection and circuits requiring time delay characteristics. It complies with UL 248-4 and CSA C22.2 standards, ensuring reliable performance and safety. This fuse has a compact size of approximately 0.41 inch diameter by 1.5 inch length and is ideal for use in Class CC fuse blocks.

Key Specifications
• Amperage: 1/4 Amp (0.25 A)
• Voltage Rating: 600 Volts AC, 300 Volts DC
• Fuse Class: Class CC
• Speed/Characteristic: Time Delay
• Dimensions: 0.41 inch diameter x 1.5 inch length
• Interrupt Rating: UL Listed for motor circuit protection
• Mounting Type: Fuse holder compatible with Class CC fuse blocks
• Certifications: UL 248-4, CSA C22.2
• Application: Motor starting inrush current protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ATDR1/4
• Manufacturer : Mersen
• Brand : Mersen
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Amp-Trap 2000
• Type : ATDR
• Voltage : 600
• Amperage : 1
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 78200190845
• GTIN : 00782001908454
• Country of Origin : Mexico
• Dimensions : x 1-1/2 in x
• Weight : 0.02
• Certification : UL/CSA
