AR3.62 - Westinghouse Thermal Overload Heater Element 2.28-3.14 Amps Plug-In Mounting Class 20

AR3.62

AR3.62 is a thermal overload heater element designed for motor control applications, providing reliable protection by detecting excessive current draw. This heater element is rated for 2.28 to 3.14 amps and is suitable for use with thermal overload relays, magnetic motor starters, and motor controls.The AR3.62 features a plug-in mounting type and is classified as a Class 20 standard trip thermal unit. It is compatible with AC/DC magnetic starters and manual starters, ensuring motor protection by triggering disconnection before damage occurs. This heater element supports a service factor of 1.15 and is designed for NEMA sizes 7 and 8.

Key Specifications
• Amperage Rating: 2.28-3.14 Amps
• Mounting Type: Plug-In
• Trip Class: 20 (Standard Trip)
• Compatible with Thermal Overload Relays and Magnetic Motor Starters
• Service Factor: 1.15
• NEMA Sizes: 7 and 8
• Application: Motor Control Protection
• Type: Thermal Overload Heater Element

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: AR3.62
• Manufacturer : Westinghouse
• Brand : Westinghouse
• Category : Motor Control
• Item Subcategory : Heater Element
• Family : AR Series
• Type : AR

Product Data

• UPC : 785901586432
• GTIN : 00785901586432
• Dimensions : Depth 9.56 in (242.82 mm) Width 18.16 in (461.26 mm) Height 31.50 in (800.10 mm)
• Weight : 0.06
