AR17.6 - Square D Thermal Overload Heater Element 11.6-16.7A Plug-In Motor Control

AR17.6

AR17.6 is a Square D thermal overload heater element designed for motor control applications.This ambient compensated bimetallic thermal unit provides reliable motor protection with a trip class 20 rating. It supports manual or automatic reset and standard trip type, suitable for use in bimetal thermal overload relays, magnetic motor starters, and motor controls. The heater element covers a full load current range approximately from 8.3 to 23.5 amps depending on the overload relay configuration, with a plug-in mounting type.

• Manufacturer: Square D
• Part Number: AR17.6
• Product Type: Thermal Overload Heater Element
• Amperage Range: 11.6 to 16.7 Amps (typical)
• Trip Class: 20
• Reset Type: Manual or Auto
• Trip Type: Standard
• Mounting: Plug-In
• Application: For use in thermal overload relays and motor starters
• Sensing Method: Ambient compensated bimetallic
• Certifications: Authentic Square D product

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: AR17.6
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Heater Element

Product Data

• UPC : 785901586074
• GTIN : 00785901586074
• Dimensions : Depth 9.5 in (241.30 mm) Width 32 in (812.80 mm) Height 91 in (2311.40 mm)
• Weight : 0.02
