Product Info
- Manufacturer:Eaton
- Sub-Category:Fuse Part And Accessory
Description
ANL-35
ANL-35 is a 35 amp low voltage limiter fuse from Eaton designed for battery operated systems and electronic device protection.
This Eaton Bussmann series ANL-35 fuse features a non-time-delay (time delay) characteristic with a stud mounting style and silver-plated connectors. It is rated for 35 amps, 32 VAC, and 80 VDC with an interrupt rating of 6 kA at 32 VAC and 2.7 kA at 80 VDC. The fuse has a visible element window for easy open status identification and is UL Recognized and SAE J1171 ignition protected. It is suitable for isolating faults in low voltage battery systems.
- Amperage: 35 A
- Voltage Rating AC: 32 VAC
- Voltage Rating DC: 80 VDC
- Interrupt Rating: 6 kA at 32 VAC, 2.7 kA at 80 VDC
- Mounting Type: Stud
- Fuse Type: Non-time-delay (time delay)
- Termination Style: Bolt Down
- Element Window: Visible
- Agency Certifications: UL Recognized, SAE J1171 ignition protected
- Series: Bussmann ANL
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: ANL-35
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Fuse Part And Accessory
- Section : Limiters
- Family : ANL Series
- Type : ANL
Product Data
- UPC : 05171270609
- GTIN : 00051712706094
- Country of Origin : Mexico
- Dimensions : 3.38 in x 1.62 in x 0.95 in (Length/Depth x Height x Width)
- Weight : 0.3
- Certification : CSA Certification Class 1422-30, SAE J1171, UL Guide JFHR2
