ANL-175 - Eaton Bussmann 175A Non-Time-Delay Low Voltage Limiter Fuse 80VDC Stud Mount

ANL-175

ANL-175 is a non-time-delay low voltage limiter fuse designed for battery-operated systems, providing reliable protection against faults. This Eaton Bussmann series fuse features a stud mounting style and is rated for 175 amps and up to 80 volts DC. The fuse is constructed with a glass/melamine body and includes a clear window for easy visual inspection of the element status. It is suitable for applications requiring fast-acting, current-limiting protection in demanding environments. The ANL-175 limiter fuse is engineered for use in isolating faults in battery-operated systems, offering a robust solution for high-current DC circuits. Its design allows for simple installation and maintenance, with a visible element to quickly identify open status. The fuse is recognized for UL and RoHS compliance, and is ignition protected per SAE J1171 for select amperage ratings.

• Part Number: ANL-175
• Manufacturer: Eaton Bussmann
• Amperage: 175 A
• Voltage Rating DC: 80 VDC
• Voltage Rating AC: 32 VAC
• Interrupt Rating DC: 2700 A
• Interrupt Rating AC: 6000 A
• Mounting Style: Stud
• Body Material: Glass/Melamine
• Series: ANL
• Response Time: Fast Blow
• Agency Approvals: UL Recognized, RoHS Compliant, SAE J1171 Ignition Protected

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ANL-175
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Fuse Parts And Accessories
• Family : ANL Series
• Type : ANL

Product Data

• UPC : 05171270615
• GTIN : 00051712706155
• Country of Origin : Mexico
• Dimensions : 3.38 in x 1.62 in x 0.95 in (Length/Depth x Height x Width)
• Weight : 0.3
• Certification : CSA Certification Class 1422-30, SAE J1171, UL Guide JFHR2
