Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Lug Terminal Kit
Description
AL1200P6KU4
AL1200P6KU4 is a mechanical lug kit designed for 1200 Amp Square D PowerPact P Frame circuit breakers, providing reliable aluminum or copper wire connections.
This lug kit includes four tin-plated aluminum lugs suitable for unit-mounted PowerPact P Frame breakers. It accepts two conductors per lug, ranging from 350 kcmil to 600 kcmil, compatible with both aluminum and copper conductors. The accessory ensures secure terminal connections for high-amperage circuit breakers in industrial and commercial applications.
- Manufacturer: Square D
- Part Number: AL1200P6KU4
- Amperage Rating: 1200 Amps
- Compatible Frame: PowerPact P Frame
- Mounting Type: Unit Mounted
- Lug Material: Tin-Plated Aluminum
- Conductor Size Range: 350 kcmil to 600 kcmil
- Conductor Type: Aluminum or Copper
- Number of Lugs: 4 per kit
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: AL1200P6KU4
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Lug Terminal Kit
- Family : Powerpact
- Type : AL
- MCM Size : 600
- Barrels : 3
- Metal Type : Aluminum
- Compatible Frames : PGL,PGP,PGM,PJL,PJP,PJM,PLL,PLP,PLM
Product Data
- UPC : 785901654728
- GTIN : 00785901654728
- Country of Origin : United States
- Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 6.001
- Certification : UL - CSA
- Wire Size : AWG 3/0...600 kcmil aluminium/copper
