Product Info
- Manufacturer:American/Federal Pacific
- Sub-Category:Low Voltage Fuse
Description
AJT5
AJT5 is a 5 amp, 600 volt AC Class J time delay fuse designed for reliable circuit protection in industrial and commercial applications.This American Federal Pacific fuse features a current-limiting design with time delay performance to protect motors, transformers, and other electrical equipment. It has a 200,000 A interrupting rating (AIC) for AC and 100,000 A for DC, complies with UL 248-8 and CSA C22.2 No. 248.8 standards, and includes a solid state SmartSpot visual blown fuse indicator. The fuse is compact with dimensions approximately 0.81 inch diameter by 2.25 inches length and mounts with a clip ferrule terminal.
- Key Specifications
- Amperage: 5A
- Voltage Rating: 600V AC, 500V DC
- Fuse Class: Class J
- Time Delay Characteristic
- Interrupt Rating: 200kA AC, 100kA DC
- Mounting Type: Clip Ferrule
- Dimensions: 0.81 in diameter x 2.25 in length
- Certifications: UL Listed, CSA Certified, IEC 269-2-1
- SmartSpot Visual Blown Fuse Indicator
- Current Limiting Design
- Part Number: AJT5
- Manufacturer : American/Federal Pacific
- Brand : American/Federal Pacific
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap 2000
- Type : AJT
- Voltage : 600
- Amperage : 5
- AIC rating : 200kA@600V
- Diameter : 0.81
- Class Rating : J
- Barrels : 1
- UPC : 782001963088
- GTIN : 00782001963088
- Weight : 5
