Product Info
- Manufacturer:Mersen
Description
AJT4.5
AJT4.5 is a Mersen Class J time-delay fuse rated for 4.5 amperes and 600 volts AC, designed for reliable circuit protection.This fuse features a clip mounting type and ferrule terminals, providing secure installation and connection. It offers a high interrupt rating of up to 200 kA at 600 VAC and 100 kA at 500 VDC, ensuring superior current-limiting performance. The AJT4.5 fuse is part of Mersen's Amp-Trap 2000 series, known for advanced material technology and IEC Type 2 no damage protection. It is UL listed and suitable for AC and DC applications, with a time-delay characteristic ideal for motor and transformer inrush currents.
- Key Specifications
- Amperage: 4.5 A
- Voltage Rating: 600 VAC / 500 VDC
- Fuse Class: Class J
- Speed/Characteristic: Time Delay
- Mounting Type: Clip
- Terminal Type: Ferrule, Tin-Plated Copper
- Interrupt Rating: 200 kA at 600 VAC, 100 kA at 500 VDC
- Series: Amp-Trap 2000
- Certifications: UL Listed
- Indication: No indication (standard)
Specifications
- Part Number: AJT4.5
- Manufacturer : Mersen
- Brand : Mersen
Product Data
- UPC : 0782001963071
- Weight : 25
