Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
AJT1-1/4
AJT1-1/4 is a 1.25 amp, 600 VAC Class J time delay fuse designed for general purpose protection in electrical circuits.This Eaton fuse features a single pole configuration with clip mounting for easy installation. It provides reliable time delay protection, suitable for use in panel accessories and power distribution applications. The fuse is cylindrical with a ferrule terminal and offers a high interrupt rating typical of Class J fuses. It complies with UL standards for safety and performance.
- Amperage: 1.25 A
- Voltage: 600 VAC
- Poles: 1
- Mounting Type: Clip Mount
- Fuse Type: Class J Time Delay
- Frame/Series: AJT
- Interrupt Rating: High (Class J standard)
- Terminal Type: Ferrule Terminal
- General Purpose Fuse
- Dimensions: Approx. 2-1/4 inch length, 13/16 inch diameter
- Certifications: UL Listed
Specifications
- Part Number: AJT1-1/4
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap 2000
- Type : AJT
- Voltage : 600
- Amperage : 1
- AIC rating : 200kA@600V
- Diameter : 0.81
- Class Rating : J
- Barrels : 1
Product Data
- UPC : 782001962746
- Weight : 5
