Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
AGC-50
AGC-50 is an Eaton Bussmann series fast-acting glass tube fuse rated for 50 amps and 32 volts AC/DC. It is designed for electronic circuit protection requiring quick response to overcurrent conditions.This fuse features a 3AG (6.3 mm x 32 mm) cartridge size with nickel-plated brass end caps and a glass tube body. It has a voltage rating of 32 Vac and 32 Vdc (self-certified) and an interrupt rating of 1 kAIC at 32 Vac. The fuse is non-indicating and requires a holder or clip for mounting. It provides fast-acting protection with a response time of 60 minutes at 135% of rated current and 120 seconds at 200% of rated current. The fuse is CE marked for compliance.
- Amperage Rating: 50 A
- Voltage Rating: 32 Vac, 32 Vdc
- Fuse Size: 3AG (6.3 mm x 32 mm)
- Mounting Type: Requires holder or clip
- Interrupt Rating: 1 kAIC at 32 Vac
- Fuse Type: Fast-acting glass tube cartridge
- End Cap Material: Nickel-plated brass
- Response Time: 60 min at 135%, 120 sec at 200%
- Fuse Indicator: Non-indicating
- Certifications: CE Marked
Specifications
- Part Number: AGC-50
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : AGC Series
- Type : AGC
- Voltage : 32
- Amperage : 50
- AIC rating : 1kA@32Vac
- Connection : Ferrule
- Diameter : 0.25
- Barrels : 1
Product Data
- UPC : 05171270459
- GTIN : 00051712704595
- Dimensions : 1.25 in x 0.25 in x 0.25 in (Length/Depth x Height x Width)
- Weight : 0.01
