Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
AG25
AG25 is a fast-acting glass tube fuse from Eaton designed for electronic circuit protection.AG25 features a 25 ampere rating and a voltage rating of 32 Vac/Vdc, with ferrule end connections for easy installation. It has a 1 kA interrupt rating at 32 Vac, ensuring reliable circuit interruption under fault conditions. This fuse is part of Eaton's Bussmann series, known for consistent performance in low voltage applications.
- Amperage Rating: 25 A
- Voltage Rating: 32 Vac / 32 Vdc (self certified)
- Interrupt Rating: 1 kA at 32 Vac
- Type: Fast-acting glass tube fuse
- Connection: Ferrule end x ferrule end
- Dimensions: 1/4 inch diameter x 1-1/4 inch length
- Fuse Indicator: Non-indicating
- Application: Electronic circuits
- Material: Glass tube with nickel-plated brass end caps
- Series: Eaton Bussmann AGC Series
- Certifications: CE Marked, RoHS Compliant
Specifications
- Part Number: AG25
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : AG
- Voltage : 480
- Amperage : 25
- AIC rating : 100kA@480V
- Diameter : 0.41
- Class Rating : G
- Barrels : 1
Product Data
- UPC : 782001905163
- GTIN : 00782001905163
- Country of Origin : Mexico
- Dimensions : x 1-5/8" x
- Weight : 0.03
- Certification : CSA Certified to C22.2 No. 248.5, UL Listed 248-5
