AG2 - Eaton 2A 250V Fast-Acting Glass Tube Fuse 1/4 x 1-1/4 Inch 100A Interrupt Rating

AG2

AG2 is a 2 amp, 250 volt fast-acting glass tube fuse from Eaton's AGC series designed for electronic circuit protection.This Eaton AG2 fuse features a 1/4 inch by 1-1/4 inch glass tube with nickel-plated brass end caps, providing reliable fast-acting protection with a 100 amp interrupt rating at 250 VAC. It is UL listed, RoHS compliant, and suitable for automotive and consumer electronics applications. The fuse has a ferrule end-to-end connection and operates effectively within a temperature range of -55°C to 125°C.

Key Specifications
• Amperage: 2 A
• Voltage Rating: 250 VAC, 32 VDC (self-certified)
• Fuse Size: 1/4" x 1-1/4" (6.3 mm x 32 mm)
• Interrupt Rating: 100 A at 250 VAC, 10 kA at 125 VAC
• Fuse Type: Fast-acting glass tube
• Connection: Ferrule end x ferrule end
• Material: Glass tube with nickel-plated brass end caps
• Certifications: UL Listed, RoHS Compliant, CE Marked
• Operating Temperature: -55°C to 125°C
• Series: Eaton Bussmann AGC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: AG2
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Amp-Trap
• Type : AG Series
• Voltage : 600
• Amperage : 2
• AIC rating : 100kA@600V
• Diameter : 0.41
• Class Rating : G
• Barrels : 1

Product Data

• UPC : 78200190507
• GTIN : 00782001905071
• Country of Origin : Mexico
• Dimensions : x 1.31 in x
• Weight : 0.02
• Certification : CSA Certified to C22.2 No. 248.5, UL Listed 248-5
