Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
AG10
AG10 is a fast-acting glass tube fuse from Eaton designed for low voltage electronic circuit protection.AG10 features a 10 ampere rating, 250 VAC voltage rating, and a 10 kA interrupting rating at 125 VAC. It has ferrule end connections and a glass tube with nickel-plated brass end caps. This fuse is non-indicating and suitable for electronic applications requiring fast response times.
- Amperage: 10A
- Voltage Rating: 250 VAC
- Interrupt Rating: 10 kA at 125 VAC
- Fuse Type: Fast-acting glass tube
- Connection: Ferrule end x ferrule end
- Material: Glass tube with nickel-plated brass end caps
- Dimensions: 1/4" x 1-1/4" (6.3 x 32 mm)
- Response Time: 60 min at 135%, 120 sec at 200%
- Non-indicating fuse
- Application: Electronic circuits
- Certifications: CE Marked
Specifications
- Part Number: AG10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : AG
- Voltage : 600
- Amperage : 10
- AIC rating : 100kA@600V
- Diameter : 0.41
- Class Rating : G
- Barrels : 1
Product Data
- UPC : 782001905132
- GTIN : 00782001905132
- Country of Origin : Mexico
- Dimensions : x 1-3/8" x
- Weight : 5
- Certification : CSA Certified to C22.2 No. 248.5, UL Listed 248-5
