Description
AF16-30-01-14
AF16-30-01-14 is a 3-pole non-reversing contactor designed for motor control applications up to 30A and 690V AC, featuring a built-in 1NC auxiliary contact and screw terminals for reliable connections. This ABB AF Series contactor is engineered for use in industrial power circuits, supporting both AC and DC control voltages from 24V to 500V. It is suitable for controlling 3-phase motors and offers high switching frequency, robust performance, and compatibility with a wide range of control systems.
- Part Number: AF16-30-01-14
- Manufacturer: ABB
- Series: AF16
- Number of Poles: 3
- Rated Current: 30 A
- Rated Voltage: 690 V AC
- Control Voltage: 24-500 V AC / 20-500 V DC
- Mounting Type: Screw Terminal
- Interrupt Rating: 600 V AC
- Number of Auxiliary Contacts: 1NC
- Operating Temperature: -40 to 70°C
- UL 508, CSA C22.2 No. 14 Certified
Additional Information
This includes a 380 VDC coil.
Specifications
- Part Number: AF16-30-01-14
- Manufacturer : ABB
- Brand : ABB
- Category : Motor Control
- Item Subcategory : Contactor
- Section : Contactors
- Family : AF Series
- Voltage : 600
- Amperage : 30
- Poles : 3
- Aux Contacts : 1 NC
- Coil Voltage Maximum : 500
- Coil Voltage Minimum : 250
Product Data
- UPC : 3471523110748
- Dimensions : 45 mm W x 77 mm D x 86 mm H
- Weight : 4
