Description
AF16-30-01-12
AF16-30-01-12 is a 3-pole, 30 amp non-reversing motor contactor from ABB designed for motor control applications up to 600 volts AC.
This ABB AF16 series contactor features a 48-130V AC/DC coil voltage range and includes one normally closed auxiliary contact. It is suitable for controlling 3-phase motors and non-inductive or slightly inductive loads with a rated operational voltage up to 690V IEC or 600V UL. The contactor supports motor loads up to 7.5 kW at 400V and offers reliable performance with screw terminal connections.
- Manufacturer: ABB
- Part Number: AF16-30-01-12
- Series: AF16 (A-Line)
- Amperage: 30A
- Poles: 3
- Voltage Rating: 600V AC (UL), 690V AC (IEC)
- Coil Voltage: 48-130V AC/DC
- Auxiliary Contacts: 1 Normally Closed (1NC)
- Type: Non-Reversing Contactor
- Application: Motor Control for 3-phase motors
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
This includes a 60 VAC coil.
Specifications
- Part Number: AF16-30-01-12
- Manufacturer : ABB
- Brand : ABB
- Category : Motor Control
- Item Subcategory : Contactor
- Section : Contactors
- Family : AF Series
- Voltage : 600
- Amperage : 30
- Poles : 3
- Aux Contacts : 1 NC
- Coil Voltage Maximum : 130
- Coil Voltage Minimum : 48
Product Data
- UPC : 3471523110724
- Dimensions : 45 mm W x 77 mm D x 86 mm H
- Weight : 5
