2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
ACK300
ACK-300 is a stud-mounted time-delay fuse designed for high-current DC circuit protection in applications such as lift trucks and battery chargers. This Eaton Bussmann series fuse provides reliable performance in demanding environments. The ACK-300 fuse is engineered for DC circuits requiring robust protection, featuring a stud-mount design for secure installation. It is rated for 300A and 48VDC, with a time-delay (slow blow) characteristic to handle temporary overloads without nuisance tripping. The fuse is non-indicating and suitable for use in battery-operated and industrial equipment.
- Part Number: ACK-300
- Manufacturer: Eaton
- Series: Bussmann ACK
- Amperage: 300A
- Voltage: 48VDC
- Mounting Type: Stud-Mounted
- Fuse Type: Time-Delay / Slow Blow
- Application: DC Circuits, Lift Trucks, Battery Chargers
- Indicator Style: Non-Indicating
- Case Length: 3.75 in
- Diameter: 27 mm
- Timing: 100 sec at 200%, 35 sec at 300%
Specifications
- Part Number: ACK300
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : ACK Series
- Type : ACK
- Voltage : 125
- Amperage : 300
- AIC rating : 10kA@125Vac/dc
- Connection : Forklift
- Diameter : 1
- Barrels : 1
Product Data
- UPC : 78200179135
- GTIN : 00782001791353
- Country of Origin : Mexico
- Dimensions : Not Applicable x 4-23/32" x
- Weight : 2
- Certification : UL Recognized Component To Standard 248-1, File E60314 JFHR2
