Product Info
- Manufacturer:American/Federal Pacific
- Sub-Category:Low Voltage Fuse
Description
A70QS25-22F
A70QS25-22F is a high speed semiconductor fuse designed for reliable circuit protection in demanding electrical applications.
This fuse features a solid-fill construction with a 22 mm diameter and 58 mm length, rated for 25 amperes. It supports a voltage rating of 690 VAC (IEC) and 700 VDC, with interrupting ratings of 200 kA AC and 100 kA DC at a 10 ms time constant. The fuse is part of the A70QS series, known for its robust performance in semiconductor protection and capacitor discharge applications up to 890 VDC for short durations. It is UL and CSA approved, ensuring compliance with safety standards.
- Key Specifications
- Amperage: 25 A
- Voltage Rating: 690 VAC (IEC), 700 VDC
- Interrupting Rating: 200 kA AC, 100 kA DC
- Fuse Size: 22 mm diameter x 58 mm length
- Series: A70QS
- Construction: Solid fill
- Approvals: UL, CSA
- Application: Semiconductor protection, capacitor discharge
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: A70QS25-22F
- Manufacturer : American/Federal Pacific
- Brand : American/Federal Pacific
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A70QS
- Voltage : 690
- Amperage : 25
- AIC rating : 200kA@690V
- Connection : Ferrule
- Diameter : 22
- Barrels : 1
Product Data
- UPC : 78200114207
- GTIN : 00782001142070
- Weight : 1
- Certification : UL Recognized Component CSA Certified IEC 269-4 Compliance
