Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
A70QS10-22F
A70QS10-22F is a 10 amp, 690V semiconductor fuse from Mersen Ferraz Shawmut designed for low voltage circuit protection.This Amp-Trap fuse features a 1-pole, round body style measuring 22mm diameter by 58mm length. It has a high interrupting rating of 200kA at 690VAC and 100kA at 700VDC, suitable for semiconductor protection and capacitor discharge applications. The fuse is extremely fast acting with current limiting characteristics, providing superior protection and longer life under cyclic loading. It meets IEC standards and is ideal for industrial and electrical equipment requiring reliable semiconductor fuse protection.
- Key Specifications
- Amperage: 10A
- Voltage Rating AC: 690VAC (IEC tested at 760VAC)
- Voltage Rating DC: 700VDC (up to 890VDC for capacitor discharge)
- Poles: 1
- Body Size: 22mm diameter x 58mm length
- Interrupting Rating: 200kA AC, 100kA DC
- Fuse Style: Amp-Trap Low Voltage Semiconductor
- Mounting Type: Cartridge fuse
- Speed: Extremely fast acting
- Certifications: IEC tested
Specifications
- Part Number: A70QS10-22F
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A70QS
- Voltage : 690
- Amperage : 10
- AIC rating : 200kA@690V
- Connection : Ferrule
- Diameter : 22
- Barrels : 1
Product Data
- UPC : 78200135883
- GTIN : 00782001358839
- Weight : 1
- Certification : UL Recognized Component CSA Certified IEC 269-4 Compliance
