A70P10-4 - Eaton 10A 700V Semiconductor Fuse Amp-Trap Form 101 High Speed

A70P10-4

A70P10-4 is a 10 Amp, 700 Volt semiconductor fuse from Eaton's Amp-Trap Form 101 series designed for high speed protection.This fuse features a cylindrical body with a 0.56 inch diameter and 2.88 inch length, providing very fast acting current limiting protection for semiconductor devices. It is rated for 700V AC and 650V DC with an interrupting rating of 100,000 AIC, suitable for protecting DC drives, UPS systems, inverters, and reduced voltage motor starters. The fuse minimizes damage to protected components with low I2t and controlled arc voltage, enhancing reliability and reducing stress during fuse clearing. It is UL recognized and tested to UL standards for AC and DC applications.

• Amperage: 10 A
• Voltage Rating: 700 V AC, 650 V DC
• Interrupting Rating: 100,000 AIC (AC and DC)
• Fuse Type: Semiconductor, High Speed
• Body Type: Cylindrical, 0.56" diameter x 2.88" length
• Mounting Type: Bolted
• Series: Amp-Trap Form 101
• UL Recognized Component (UL File E60314)
• Applications: DC drives, UPS, inverters, reduced voltage starters
• Controlled arc voltage reduces stress on circuit components

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A70P10-4
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Amp-Trap
• Type : A70P
• Voltage : 700
• Amperage : 10
• AIC rating : 100kA@700V
• Connection : Bolt-In Blade
• Diameter : 0.56
• Barrels : 1

Product Data

• UPC : 782001948092
• GTIN : 00782001948092
• Weight : 5
