Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
A6Y500-4
A6Y500-4 is a Mersen AMP-TRAP® Type 4 special purpose DC fuse designed for high-amperage circuit protection in demanding electrical environments. This fuse provides reliable performance for both AC and DC applications with a robust cylindrical body construction.Engineered for use in industrial and commercial power distribution systems, the A6Y500-4 offers a 500A current rating and supports up to 600VAC or 500VDC. It features a clip mounting style and is suitable for applications requiring high interrupt capacity. The fuse is UL approved and built to withstand harsh operating conditions.
- 500A Amperage Rating
- 600VAC / 500VDC Voltage Rating
- 200kA Interrupt Rating at 250VAC
- 100kA Interrupt Rating at 500VDC
- Type 4 Special Purpose Fuse
- Cylindrical Body Design
- Clip Mounting Style
- UL Approved
- 13-3/8 Inch Length
- 2-1/2 Inch Diameter
- Max Operating Temperature: 80°C
Specifications
- Part Number: A6Y500-4
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A6Y
- Voltage : 600
- Amperage : 500
- AIC rating : 200kA@600V
- Connection : Plug-In
- Diameter : 2.5
- Class Rating : K
- Barrels : 1
Product Data
- UPC : 782001908119
- GTIN : 00782001908119
- Weight : 5
