Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
A6Y450-3
A6Y450-3 is a 450 Ampere, 600 Volt AC current-limiting fuse designed for low voltage power distribution applications.
The A6Y450-3 Amp-Trap fuse features a Type 3 blade configuration with clip mounting for secure installation in fuse holders. This Class K fuse delivers 200 kA interrupt rating at 250 VAC and 100 kA at 500 VDC, providing reliable overcurrent protection for main, feeder, and branch circuits. The fuse body is constructed with glass melamine insulation and plated terminals for superior reliability in demanding environments. Blade-stamped catalog numbers ensure permanent identification.
- Amperage Rating: 450 A
- Voltage Rating: 600 VAC / 500 VDC
- Interrupt Rating: 200 kA at 250 VAC, 100 kA at 500 VDC
- Fuse Type: Class K, Type 3 Blade
- Mounting Type: Clip
- Insulation Material: Glass Melamine (GMG)
- Maximum Operating Temperature: 80 degrees C
- Current-Limiting Design: Yes
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: A6Y450-3
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A6Y
- Voltage : 600
- Amperage : 450
- AIC rating : 200kA@600V
- Connection : Plug-In
- Diameter : 2.5
- Class Rating : K
- Barrels : 1
Product Data
- UPC : 782001907938
- GTIN : 00782001907938
- Weight : 5
