Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
A6Y110-3
A6Y110-3 is a Class K low voltage fuse designed for reliable circuit protection in industrial and commercial applications. This fuse features a blade non-rejection connection and is built for durability and safety in demanding environments.Engineered for use in panel accessories, the A6Y110-3 offers a compact design with a single barrel configuration. It is suitable for systems requiring 600V operation and provides effective overcurrent protection for sensitive equipment.
- Amperage: 110A
- Voltage: 600V
- Connection Type: Blade Non-Rejection
- Diameter: 1.5 inches
- Barrels: 1
- Interrupt Rating: 200 kAIC
- Insulation Material: GMG
- Max Operating Temperature: 80°C
- Frequency: 50 Hz
- Type: A6Y
- Series: Form 600
- Weight: 1.21 lbs
Specifications
- Part Number: A6Y110-3
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A6Y
- Voltage : 600
- Amperage : 110
- AIC rating : 200kA@600V
- Connection : Blade Non-Rejection
- Diameter : 1.5
- Class Rating : K
- Barrels : 1
- Velocity : GP - General Purpose
Product Data
- UPC : 782001905699
- GTIN : 00782001905699
- Weight : 1
