Product Info
- Manufacturer:Eaton
- Sub-Category:Medium Voltage
Description
A550X100E-1
A550X100E-1 is a 100 amp, 5.5 kV Class E medium voltage fuse designed for reliable circuit protection.This Eaton fuse features a Class E rating compliant with ANSI C37.46 standards, providing a defined melting time-current characteristic for electrical interchangeability. It has an interrupting rating of 63kA RMS symmetrical at 5.5 kV, suitable for motor circuits and feeder protection in medium voltage applications.
- Key Specifications
- Amperage: 100 A
- Voltage Rating: 5.5 kV
- Fuse Class: E-Rated
- Interrupting Rating: 63 kA RMS Symmetrical
- Compliance: ANSI C37.46
- Typical Applications: Motor circuits, feeder circuits, switchgear, transformer protection
- Manufacturer: Eaton
- Mounting Type: Medium voltage fuse mounting (bolt-on or clip-lock depending on application)
- Part Number: A550X100E-1
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Medium Voltage
- Family : CS-3 Series
- Type : A055
- Voltage : 5500
- Amperage : 100
- AIC rating : [email protected]
- Connection : Ferrule
- Diameter : 3
- Class Rating : E
- Barrels : 1
- Clip Center : 12
- Weight : 11
