Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
A4BX2000-55AL
A4BX2000-55AL is a high-performance Class L time-delay fuse from Mersen, designed for service entrance and feeder circuit protection. This Amp-Trap 2000 series fuse offers reliable, current-limiting protection for demanding electrical applications. The A4BX2000-55AL features a 2000A rating and is built for use in 600V AC systems. Its time-delay characteristic allows it to handle normal inrush currents without nuisance tripping, making it ideal for protecting motors, transformers, and other high-inrush loads. The fuse is constructed with a glass melamine body and plated terminals for durability in harsh environments.
- Part Number: A4BX2000-55AL
- Manufacturer: Mersen
- Series: Amp-Trap 2000
- Fuse Class: Class L
- Amperage: 2000A
- Voltage: 600V AC
- Speed/Characteristic: Time Delay
- Frequency: 50/60 Hz
- UL Category Code: JDDZ
- UL File Number: E2137
- CSA File Number: Class 1422-02 Guide 012636_0
- Max Operating Temperature: 80 °C
- Max Storage Temperature: 80 °C
- Min Storage Temperature: -25 °C
- Harmonized System Code: 853610
- REACH Compliant
Specifications
- Part Number: A4BX2000-55AL
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A4BX
- Voltage : 600
- Amperage : 2000
- Connection : Bolt-In
- Class Rating : L
Product Data
- UPC : 78200193965
- GTIN : 00782001939656
- Weight : 8
