A4BQ2000-4TA - Eaton Class L Time-Delay Fuse 600VAC 500VDC 2000A with TA Indicator

A4BQ2000-4TA

A4BQ2000-4TA is a Class L time-delay fuse designed for high-performance circuit protection in industrial and commercial applications. This fuse features a 2000A current rating, 600VAC and 500VDC voltage ratings, and a built-in TA mechanical indicator for easy status monitoring. The Amp-Trap 2000 series offers superior current limiting and time-delay characteristics, making it ideal for service entrance and high-inrush environments.Engineered for reliable operation, the A4BQ2000-4TA fuse provides fast short-circuit response and accommodates high inrush currents without nuisance tripping. Its rejection-style design prevents incorrect replacement, and the high-visibility orange label ensures instant brand recognition. The fiberglass body delivers dimensional stability in harsh conditions, while the high-grade silica filler enables rapid arc quenching.

• 2000A current rating
• 600VAC / 500VDC voltage rating
• Class L time-delay fuse
• TA mechanical indicator included
• Blade terminal type
• Bolted mounting
• 3.5 inch diameter
• Current-limiting design
• 4-second time-delay at 500% rated current
• Rejection-style body
• High-visibility orange label
• Fiberglass body construction

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A4BQ2000-4TA
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Amp-Trap 2000
• Type : A4BQ
• Voltage : 600
• Amperage : 2000
• AIC rating : 200kA@600V
• Connection : Bolt-In Blade
• Diameter : 3.5
• Class Rating : L
• Barrels : 1

Product Data

• UPC : 78200129411
• GTIN : 00782001294113
• Weight : 9
