Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
A30QS15-1
A30QS15-1 is a fast-acting semiconductor fuse designed for protection of power semiconductors with a 15 ampere rating and 300 volts AC/DC voltage capacity.This Eaton A30QS Series fuse features a bolt-on ceramic body style, single pole design, and high interrupt rating of 200kA at 300V AC and 100kA at 300V DC. It provides current-limiting protection with low I2t, suitable for heavy-duty rectifiers and power supplies. The fuse is UL recognized and designed for reliable semiconductor protection.
- Amperage: 15A
- Voltage: 300V AC / 300V DC
- Poles: Single Pole
- Mounting Type: Bolt-On
- Interrupt Rating: 200kA AC, 100kA DC
- Series: A30QS
- Body Material: Ceramic
- Speed Type: Fast Acting
- Visual Indication: Non-Indicating
- Fuse Diameter: 9/16 inch
- Fuse Length: 2 inches
- Certifications: UL Recognized Component
Specifications
- Part Number: A30QS15-1
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : Amp-Trap
- Type : A30QS
- Voltage : 300
- Amperage : 15
- AIC rating : 200kA@300V
- Connection : Ferrule
- Diameter : 0.56
- Barrels : 1
Product Data
- Weight : 5
