Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
A2Y600-3
A2Y600-3 is a high-performance Form 600 fuse designed for demanding AC and DC applications, offering reliable protection with a 600A current rating and 250VAC/500VDC voltage rating. This Type 3 blade mount fuse is ideal for special fusing requirements where current limitation and safety are critical. The A2Y600-3 fuse features a GMG body insulating material and is dimensionally interchangeable with Class H and K fuses. It provides a high degree of current limitation in both AC and DC circuits, making it suitable for a wide range of industrial and commercial power distribution systems.
- Amperage Rating: 600 A
- Voltage Rating AC: 250 VAC
- Voltage Rating DC: 500 VDC
- Mounting Type: Blade Mount
- Interrupt Rating AC: 200 kA
- Interrupt Rating DC: 100 kA
- Series/Frame: Form 600
- Type: Type 3
- Body Insulating Material: GMG
- UL Approval: Yes
- Frequency: 50/60 Hz
- Max Operating Temperature: 80 °C
Specifications
- Part Number: A2Y600-3
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Voltage : 250
- Amperage : 600
- AIC rating : 200kA@250V
- Connection : Blade
- Diameter : 2.5
- Class Rating : K
- Barrels : 1
Product Data
- UPC : 078200190871
- GTIN : 00782001908713
- Weight : 4
