Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
A2D3R
A2D3R is a Class RK1 time-delay fuse from Eaton designed for low voltage circuit protection with a 3 ampere rating and 250VAC voltage capacity.This Eaton A2D3R fuse features a 3 amp current rating, 250 volts AC and DC rating, and a time-delay characteristic suitable for motor starting and transformer inrush currents. It has a single pole design with clip mounting and a high interrupt rating of 200kA for reliable protection. The fuse body is made of PolyTube insulating material with tin-plated copper ferrule terminals. It is UL listed, CSA certified, and RoHS compliant.
- Amperage: 3 A
- Voltage: 250 VAC / 250 VDC
- Poles: 1
- Mounting Type: Clip
- Interrupt Rating: 200 kA
- Fuse Class: RK1
- Speed/Characteristic: Time Delay
- Terminal Type: Ferrule
- Body Material: PolyTube
- Certifications: UL Listed, CSA Certified, RoHS Compliant
- Connection Material: Tin-Plated Copper
- Product Length: 2 in
Specifications
- Part Number: A2D3R
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap 2000
- Type : A2D-R
- Voltage : 250
- Amperage : 3
- AIC rating : 200kA@250V
- Diameter : 0.56
- Class Rating : RK1
- Barrels : 1
Product Data
- UPC : 782001990688
- GTIN : 00782001990688
- Country of Origin : Mexico
- Dimensions : x 2" x
- Weight : 0.04
- Certification : CSA C22.2 No. 248.12, DC UL 248, UL 248-12 File E2137
