Product Info
- Manufacturer:Mersen
- Sub-Category:Low Voltage Fuse
Description
A2D15R
A2D15R is a Mersen 15 Amp, 250 Volt AC/DC Class RK1 time delay fuse with clip mounting and 200kA interrupting rating.
This A2D15R fuse provides reliable time-delay protection for motors, transformers, safety switches, and general-purpose circuits. It features a SmartSpot indicator and PolyTube insulation for enhanced durability. Designed to handle motor inrush currents without nuisance opening, it meets UL 248/248-12 and CSA C22.2 certifications and offers IEC Type 2 "no damage" protection to prevent damage to motor starters and other components.
- Key Specifications
- Amperage: 15 Amps
- Voltage Rating: 250 VAC/VDC
- Fuse Class: RK1
- Time Delay Characteristic
- Interrupting Rating: 200kAIC
- Mounting Type: Clip
- Insulation Material: PolyTube
- SmartSpot Indicator
- Series: A2D-R
- Certifications: UL 248/248-12, CSA C22.2
- Part Number: A2D15R
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap 2000
- Type : A2D-R
- Voltage : 250
- Amperage : 15
- AIC rating : 200kA@250V
- Diameter : 0.56
- Class Rating : RK1
- Barrels : 1
- UPC : 782001990824
- GTIN : 00782001990824
- Weight : 0.04
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
