Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
A15QS50-1
A15QS50-1 is a fast-acting semiconductor protection fuse designed for the specific protection of diodes and other semiconductor devices rated 150VAC/DC. This Amp-Trap Form 101 fuse features a compact design ideal for space-limited applications and delivers low I2t to minimize damage to protected components during short circuit events. A15QS50-1 fuses provide controlled arc voltage to reduce stress to circuit components during fuse clearing and are available in multiple mounting types for unique termination requirements. The fuse body is constructed from fiberglass with tin-plated brass connection material and single element design.
- Amperage: 50A
- Voltage Rating: 150VAC / 150VDC
- Speed: Fast-Acting
- Current Limiting: Yes
- Interrupt Rating AC: 100 kA
- Interrupt Rating DC: 50 kA
- Mounting Type: Ferrule, Midget Dimensions (10x38mm)
- Physical Size: 0.81 inch x 2.00 inch
- Body Material: Fiberglass
- Connection Material: Tin-Plated Brass
- UL Recognition: UL File E60314
- Standards: UL Guide JFHR2 (1-4000A AC); UL Standard 198L (1-4000A DC)
Specifications
- Part Number: A15QS50-1
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : Amp-Trap
- Voltage : 150
- Amperage : 50
- AIC rating : 100kA@150V
- Connection : Ferrule
- Diameter : 0.81
- Barrels : 1
Product Data
- Weight : 5.19
