Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
A150X250-4
A150X250-4 is a 250 Amp, 1500 Volt semiconductor fuse designed for fast acting current limiting protection in electrical circuits.A150X250-4 features a rugged fiberglass body with heavy duty links, measuring 2 inches in diameter and 7.87 inches in length. It is rated for 1500V AC/DC with an interrupting rating of 100,000 AIC, suitable for protecting traction drive and auxiliary circuits. This fuse is part of the Amp-Trap Form 101 series and is UL listed for North America.
- Key Specifications
- Amperage: 250 Amps
- Voltage Rating: 1500 Volts AC/DC
- Fuse Type: Semiconductor, Fast Acting
- Interrupting Rating: 100,000 AIC (AC and DC)
- Physical Size: 2" Diameter x 7.87" Length
- Mounting Type: Blade Bolt-In
- Series/Frame: Amp-Trap Form 101
- Body Material: Rugged Fiberglass
- Certifications: UL Listed (Canada and US)
Specifications
- Part Number: A150X250-4
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Amp-Trap
- Type : A150X
- Voltage : 1500
- Amperage : 250
- AIC rating : 100kA@1500V
- Connection : Ferrule
- Diameter : 2
- Barrels : 1
Product Data
- UPC : 782001949662
- GTIN : 00782001949662
- Weight : 3
