A100P800-4 - Mersen 800A 1000VAC 750VDC High Speed Semiconductor Fuse, Amp-Trap® Series, Bolted Blade, 100kA Interrupt, UL Recognized

A100P800-4

A100P800-4 is a Mersen high speed semiconductor fuse designed for robust protection in demanding power electronics applications.

This fast-acting, current-limiting fuse is part of the Amp-Trap® A100P series, offering superior reliability and low I2t for minimized damage to protected components during short circuits. It is engineered for the protection of UPS systems, AC and DC drives, reduced voltage motor starters, and similar equipment up to 1000VAC or 750VDC. The controlled arc voltage reduces stress on circuit components during fuse clearing, and the fuse is available with an optional blown-fuse indicator.

Key Specifications
• Amperage: 800A
• Voltage: 1000VAC, 750VDC
• Poles: Single
• Mounting Type: Bolted blade
• Interrupt Rating: 100,000A (100kA) AC/DC
• Series/Frame: Amp-Trap® A100P, Form 101
• Trip Unit: Fast acting, current limiting
• Certifications: UL Recognized Component (File E60314), UL Guide No. JFHR2 (35-600A), DC self-certified
• Physical Size: 2.88" diameter x 7.44" length
• Connection/Terminal Material: Silver-plated copper
• Application: Semiconductor protection in UPS, drives, inverters, motor starters
• Optional Features: Blown-fuse indicator (trigger indicator)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: A100P800-4
• Manufacturer : Mersen
• Brand : Mersen
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Amp-Trap
• Type : A100P
• Voltage : 1000
• Amperage : 800
• AIC rating : 100kA@1000V
• Diameter : 2.88
• Barrels : 1

Product Data

• UPC : 78200194973
• GTIN : 00782001949730
• Weight : 3
• Certification : UL
