Product Info
- Manufacturer:Mersen
- Sub-Category:Medium Voltage Fuse
Description
A055F1DSR0-25E
A055F1DSR0-25E is a 5.5kV ferrule mount current-limiting fuse designed for transformer protection applications. This medium voltage fuse is engineered to withstand transformer magnetizing inrush current while providing superior equipment protection through current-limiting technology. The fuse features a 63kA interrupt rating (symmetric) and is available in multiple barrel sizes including 2 inch (size C), 3 inch (size D), and 2x3 inch (size DD) configurations to accommodate various installation requirements.
- Amperage Rating: 25E
- Voltage Rating: 5.5kV AC
- Interrupt Rating: 63kA RMS Symmetric
- Mounting Type: Ferrule Mount
- Barrel Sizes: 2 inch (C), 3 inch (D), 2x3 inch (DD)
- Application: Transformer Protection
- Technology: Current-Limiting
- Inrush Current Withstand: Yes
Specifications
- Part Number: A055F1DSR0-25E
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Medium Voltage Fuse
- Family : CS-3 Series
- Type : A055F
- Voltage : 5500
- Amperage : 25
- AIC rating : [email protected]
- Connection : Ferrule
- Diameter : 3
- Class Rating : E
- Barrels : 1
- Clip Center : 12
Product Data
- UPC : 78200180252
- GTIN : 00782001802523
- Weight : 7
