9T58K4500G09 - General Electric Single-Phase Pole-Type Transformer, 34.5 kV HV, Direct-to-Pole Mounting, ANSI Certified

SKU: 9T58K4500G09-New
Condition: New
Price:
$192.36
Stock:
14 In stock, ready to be shipped

💡 ABB / GE Branding Notice

On June 30, 2018, ABB completed the acquisition of GE Industrial Solutions.

As a result of this transition, certain products may be labeled as either ABB or GE depending on the manufacturing date and production batch. In many cases, the product itself remains identical in form, fit, function, and specifications, with only the branding or label differing.

Customers may receive:

  • ABB-branded products
  • GE-branded products
  • Packaging reflecting either brand

Unless otherwise stated, these are considered the same product and are fully interchangeable under the applicable manufacturer specifications.

If you have questions regarding labeling, compatibility, or product identification, please contact our support team prior to ordering.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

9T58K4500G09 - General Electric Single-Phase Pole-Type Transformer, 34.5 kV HV, Direct-to-Pole Mounting, ANSI Certified - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
9T58K4500G09 - General Electric Single-Phase Pole-Type Transformer, 34.5 kV HV, Direct-to-Pole Mounting, ANSI Certified - Essential Electric Supply

Description

9T58K4500G09


9T58K4500G09 is a General Electric single-phase pole-type distribution transformer designed for utility overhead systems.This transformer features a mild steel tank with welded lifting lugs and hanger brackets for direct-to-pole mounting. It meets or exceeds ANSI, IEEE, NEMA, and RUS standards including C57.12.00 and C57.12.20. The unit is built for high reliability with high-voltage porcelain cover-mounted bushings and low-voltage tank wall-mounted bushings. It includes tin-plated bronze terminals compatible with copper or aluminum conductors and provisions for low-voltage and tank grounding. The transformer is available with mineral oil or natural ester fluid and is tested for leak, polarity, resistance, load losses, and voltage withstand.
    Key Specifications
    • Type: Single-Phase Pole-Type Transformer
    • High Voltage Rating: Up to 34.5 kV
    • Mounting: Direct-to-Pole with welded lifting lugs and hanger brackets
    • Standards: Meets ANSI C57.12.00, ANSI C57.12.20, IEEE, NEMA, RUS
    • Tank Material: Mild steel
    • Bushing Type: Porcelain high-voltage and porcelain/polymer low-voltage
    • Terminals: Tin-plated bronze for copper or aluminum conductors
    • Fluid Type: Mineral oil or natural ester fluid options
    • Testing: Leak, polarity, resistance, load losses, applied voltage, impulse
    • Cover: Single-piece clamped cover band for ANSI cover retention
    • Corrosion Protection: Electrostatically applied polyester powder paint
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: 9T58K4500G09
  • Manufacturer : General Electric
  • Brand : General Electric
  • Category : Transformer
  • Item Subcategory : Dry Type
  • Type : 9T5
  • Phase : 1
  • KVA Rating : 0.05
  • Primary Voltage : 208
  • Secondary Voltage : 120

Product Data

  • UPC : 783173154137
  • GTIN : 00783173154137
  • Dimensions : Height 68 mm 2.7 in x Depth / Length 102 mm 4 in x Width 78 mm 3.1 in
  • Weight : 3.12
