Description
9F61BNW748
9F61BNW748 is a 3-pole fuse holder from Mersen designed for DIN-rail mounting with a compact footprint and finger-safe protection.9F61BNW748 features a compact 45mm width design, suitable for Class CC fuses such as ATDR, ATQR, and ATMR. It includes a visual blown fuse indicator option and allows padlocking in the open position with a 1/4 inch shank diameter. The holder supports wire sizes from #14 to 6 AWG single conductor and #14 to 10 AWG dual conductor, with terminal screws accepting Phillips/slot heads and a suggested torque of 14.75 in-lbs. It is RoHS compliant and lead free, providing environmentally conscious construction.
- 3-pole fuse holder
- DIN-rail mounting
- Finger-safe to IP20 IEC standard
- Compact 45mm width footprint
- Visual blown fuse indicator option
- Padlockable in open position (1/4 inch shank)
- Wire range: #14 to 6 AWG single conductor, #14 to 10 AWG dual conductor
- Phillips/slot head terminal screws
- Suggested screw torque: 14.75 in-lbs
- RoHS compliant and lead free
Specifications
- Part Number: 9F61BNW748
- Manufacturer : Mersen
- Brand : Mersen
- Category : Fuse
- Item Subcategory : Fuse Clip
Product Data
- UPC : 78200139863
- GTIN : 00782001398637
- Weight : 11
