9998SAC62 - Square D 480V AC Magnetic Coil Class 9998 NEMA 00 Frame

9998SAC62

9998SAC62 is a Square D magnetic coil designed for motor control applications with a voltage rating of 480V AC. It is part of the Class 9998 series and fits NEMA 00 frame contactors and motor starters.

This magnetic coil operates at 440/480 VAC with 50/60 Hz frequency and is compatible with various Square D NEMA 00 type contactors and motor starters, including models 8502, 8536, 8538, 8539, 8606, 8630, 8640, 8647, 8650, 8651, 8702, 8736, 8739, 8810, 8811, 8812, 8903, and 8910. It features solid-state protection and supports a 3-pole draw-out connection, ensuring reliable performance in motor control circuits.

• Manufacturer: Square D
• Part Number: 9998SAC62
• Voltage: 480V AC (440/480 VAC 50/60 Hz)
• Series: Class 9998
• Type: Magnetic Coil (SAC)
• Frame: NEMA 00
• Compatible with multiple NEMA 00 contactors and motor starters
• 3-pole draw-out connection
• Solid-state protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 9998SAC62
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Magnetic Coil
• Voltage : 600
• Amperage : 4000
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Draw-Out
• Functions : LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm
• Protection : Solid State

Product Data

• UPC : 78590177097
• GTIN : 00785901770978
• Dimensions : 2.2 in (54.7 mm) x 3.2 in (81.5 mm) x 2.2 in (56.2 mm) (Height x Width x Depth)
• Weight : 0.45
