Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Magnetic Coil
Description
9998L23
9998L23 is a Square D Class 8903 replacement magnetic coil designed for multipole lighting contactor applications. This 24VAC 60Hz coil is engineered for reliable control of fluorescent and tungsten lighting loads in commercial and industrial lighting systems.Technical Specifications: The coil operates at 24 volts AC at 60 Hz frequency with an inrush power rating of 150 VA and an average sealed consumption of 30 VA. It is compatible with 8903L multipole lighting contactors rated to switch up to 30 amperes of fluorescent lighting loads and 20 amperes of tungsten lighting loads. The coil supports 2 to 6 poles configuration and is part of the Square D 9998 series contactor family.
- Part Number: 9998L23
- Manufacturer: Square D (Schneider Electric)
- Voltage Rating: 24VAC
- Frequency: 60 Hz
- Inrush Power: 150 VA
- Sealed Consumption: 30 VA
- Application: Lighting Control Contactors
- Fluorescent Load Rating: 30A
- Tungsten Load Rating: 20A
- Poles: 2 to 6
- Series: Class 8903
- UPC: 785901081203
Specifications
- Part Number: 9998L23
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Motor Control
- Item Subcategory : Magnetic Coil
- Family : Class 8903
- Type : LX
- Voltage : 24
Product Data
- UPC : 785901081203
- GTIN : 00785901081203
- Dimensions : 2.4 in (60.5 mm) x 2.1 in (53.6 mm) x 1.5 in (37.1 mm) (Height x Width x Depth)
- Weight : 0.36
