9080GC6 - Square D Linergy Terminal Block 110A 600V Box Connector

9080GC6

9080GC6 is a Square D Linergy terminal block designed for electrical motor control applications requiring a box connector.This terminal block supports up to 110 amps and 600 volts, accommodating solid or stranded copper wires from 18 to 4 AWG. It features zinc-plated steel lug terminals with torque specifications of 32-35 lbf.in for secure connections. The natural-colored block is suitable for DIN rail mounting and provides reliable electrical connectivity in motor control circuits.

Key Specifications
• Manufacturer: Square D
• Part Number: 9080GC6
• Type: Linergy Terminal Block
• Amperage: 110 Amps
• Voltage Rating: 600 Volts
• Wire Range: 18 to 4 AWG copper
• Terminal Type: Box Connector
• Terminal Material: Zinc Plated Steel
• Torque Rating: 32-35 lbf.in
• Color: Natural
• Mounting: DIN Rail Compatible
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: 9080GC6
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Terminal Blocks
• Section : Terminal Blocks
• Family : 9080G
• Voltage : 600 600 /DC
• Temp Rating : -13–158 °F (-25–70 °C)



Product Data

• UPC : 785901155065
• GTIN : 785901155065
• Country of Origin : Mexico
• Dimensions : 2.13 in (54.10 mm) x 1.99 in (50.55 mm) x 0.43 in (10.92 mm) (Height x Width x Depth)
• Weight : 0.05 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CE, CSA Approved, RoHS Compliant, UL Component Recognized
