9070T3000D1 - Square D 3000VA 1-Phase Industrial Control Transformer 240/480V Primary 120V Secondary

9070T3000D1

9070T3000D1 is a 3000VA single-phase industrial control transformer designed for reliable control power applications. This Square D Type T transformer features a 240/480V primary and 120V secondary, suitable for a wide range of industrial environments. It is panel mountable with screw clamp terminals for secure connections and includes copper windings for durability and efficiency. The device is compatible with Square D finger safe covers and control power fuse kits, and is rated for 50/60 Hz operation. This transformer is UL, CSA, and NOM listed, meeting RoHS and REACh standards. It features a 115°C temperature rise and 180°C insulation temperature, ensuring safe operation under demanding conditions. The open enclosure design allows for easy integration into control panels and motor control centers.

• Part Number: 9070T3000D1
• Manufacturer: Square D
• Type: Industrial Control Transformer
• Power Rating: 3000 VA
• Phase: 1
• Primary Voltage: 240/480V AC
• Secondary Voltage: 120V AC
• Mounting Type: Panel
• Terminal Connection: Screw Clamp
• Temperature Rise: 115°C
• Insulation Temperature: 180°C
• Certifications: UL, CSA, NOM, RoHS, REACh

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 9070T3000D1
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Motor Control
• Item Subcategory : Transformers
• Section : Control
• Temp Rating : -13–158 °F (-25–70 °C)

Product Data

• UPC : 785901876083
• GTIN : 00785901876083
• Country of Origin : United States
• Dimensions : 8.75 in (222.25 mm) x 9 in (228.6 mm) x 7.24 in (183.90 mm) (Height x Width x Depth)
• Weight : 65.751
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CSA File LR37055 Guide 184-N-90, REACH, RoHS, UL Listed File E61239
